The Original Lyncole XIT® Grounding System

The XIT Grounding System was the original patented electrolytic ground rod system. With today’s sensitive electronics, don’t protect them with a grounding system from yesterday. We have invented the Lyncole XIT Grounding System for today’s digital facilities.

Get In Touch

Ensure safety, with the best.

The Lyncole XIT® Grounding system now with the only full replacement and 25 Ohm warranty.

That’s right, the XIT System is guaranteed to reach 25 Ohms on most soils and last 30 years. If it fails to do so, Lyncole will not only replace the rod but install the replacement.

Satisfy your high-performance grounding needs today and be protected in the future.

Benefits of the Lyncole XIT Grounding System:

Consistent, low impedance, and low resistance earth ground
50-year life expectancy
30-year / 25 Ohm maintenance-free full replacement warranty
No hazardous materials or chemicals used in producing XIT rods
Continuously UL listed since 1982
Lynconite II® backfill material provides a pH balanced environment, inhibiting corrosion
Active grounding system replenishes soil moisture, no watering necessary!
System performance improves over time as electrolytic roots form

Lyncole XIT® Grounding System (K2-10CSXD)

K = Type K hard copper
2 = Internal diameter of the XIT Electrode (in inches)
10 = Length of electrode in feet (Electrode length can be as long as desired in 10 foot increments)
CS = Complete System including, Fibrelyte Cover Box, Lynconite II® backfill and exothermically welded tail
X = Tail conductor size, 4/0, 2/0, #2, #2T (please call for additional options)
D/U/P = Tail orientation (down, up, or pass-through), can also accommodate multiple tails

Lynconite II Backfill Material

Environmentally safe (NSF 60 Certified)
Has a low resistivity of 0.6 Ohms/m
Is not corrosive, unlike carbon based enhancement backfills
Can be used where soil is corrosive to extend the life of regular rods and conductor
Lowers ground system resistance
Provides a pH balanced environment, inhibiting corrosion

Lynconite II

Additional System Features

Traffic-rated test wells available
Standard models have a 30 year / 25 Ohm full replacement warranty, with a 50 year expected life
Heavy duty models have 35 and 40 year warranties
Technical and installation support
No maintenance
25 Ohm warranty applicable in soils with a resistivity of 100 or less which covers most local soils
